OPERATING FLUIDS

Metric

Imperial

Tank capacity

5,00 l

1,3 gal US

Exciter oil volume

0,75 l

0,79 qt US

Hydraulic fluid type

Renolin MR 520

Renolin MR 520

Hydraulic fluid volume

0,500 l

0,5 qt US

Exciter oil type

75W-90 API GL-4

75W-90 API GL-4

ENGINE

Metric

Imperial

Inclined position max.

25,0 °

25,0 °

Engine operating mode

four-stroke

four-stroke

Operating Engine speed

2.800 1/min

2.800 1/min

Fuel consumption

2,10 L/Std

0,6 GPH US

CO2 (NRSC)

888,00 g/KWh

888,00 g/KWh

Standard (Power max.)

ISO 3046 IFN

ISO 3046 IFN

Standard (Effective power)

ISO 3046 IFN

ISO 3046 IFN

Nominal Engine speed

2.800 1/min, 3.000 1/min

2.800 1/min, 3.000 1/min

Oil filling max.

1,60 l

0,4 gal US

Effective power

7,3 kW, 7,6 kW

9,8 hp, 10,2 hp

Battery capacity (nom. value)

45 Ah

45 Ah

Air cleaner

Dry air filter

Dry air filter

Power rating max.

7,9 kW

10,6 hp

fuel type

Diesel EN 590

Diesel EN 590

Cooling

air cooling

air cooling

Exhaust-gas limit

EPA Tier 4 final

EPA Tier 4 final

Oil specification

SAE 10W-40

SAE 10W-40

Starter battery Voltage

12 V

12 V

Engine speed (Power max.)

3.600 1/min

3.600 1/min

Starter type

E-starter

E-starter

Upper idling speed ex load

3.080 1/min

3.080 1/min

Operating power

7,3 kW

9,8 hp

Oil filling min.

0,80 l

0,2 gal US

Engine type

Diesel engine

Diesel engine

Cylinder

1

1

Engine Manufacturer

Hatz

Hatz

Standard (Operating power)

ISO 3046 IFN

ISO 3046 IFN

Cylinder capacity

517 cm3

31,5 Inch3

MECHANICAL - OUTPUT DETAILS

Metric

Imperial

Vibrations

4.140 1/min

4.140 1/min

Forward running

30,00 m/min

1,6 fps

Transmission

FKR

FKR

Centrifugal force

62,000 kN

13.938 lbf

Vibrations (Hz)

69,0 Hz

69,0 Hz

Area capacity

1.350 m2/h

14.531,4 ft2/h

MECHANICAL DETAILS

Metric

Imperial

Lenght Drawbar in op. pos.

1.780 mm

70,1 "

Operating weight

510,0 kg

1.124,4 lb

Height

1.449 mm

57,0 "

Underclearance

877 mm

34,5 "

Width

750 mm

29,5 "

ENVIRONMENT DATA

Metric

Imperial

Operating temperature range

-15 - 40 °C

5 - 104 °F

Sound level LpA (Standard)

EN 500-4

EN 500-4

Sound power LWA, guaranteed

108,0 dB(A)

108,0 dB(A)

Storage temperature range

-15 - 40 °C

5 - 104 °F

HAV summation (average value)

< 2,5 m/s2

8,2 ft/s2

Uncertainty in measurement HAV

0,5 m/s2

1,6 ft/s2

HAV summation (Standard)

EN 500-4

EN 500-4

Sound level LpA

91,0 dB(A)

91,0 dB(A)

Sound power LWA (Standard)

EN 500-4

EN 500-4

Sound power LWA, measured

107,0 dB(A)

107,0 dB(A)

Custom Attributes

Metric

Imperial

Model serie

DPU
